1. Accurate: Even the belt speed up to 60m/min, the measurement accuracy of weight and volume can still be guaranteed, more than 1800pcs/hour can be tested.
2. Easy to install and maintain. Flexible module design can satisfy varies customers needs, convenient for customers to customize and expend their functions
Capability |
Up to 1800 pcs per hour |
Conveying Speed |
10-60 m/min |
Operating Temperature |
-10~40 degree |
Electrical |
1-phase 115/230VAC, 50/60 HZ |
Conveyor Height |
450mm±50mm |
Interface Options |
RS485/232, Ethernet |
Code Options |
Manual Scanner |
Code Type |
One-Dimension Code or QR Code |
Code Direction |
Parallel or Vertical |
Code Position |
On the top or side(3 and 5 sides scanning customizable) |
Max Weight |
50kg |
Tolerance |
Weight: ±50g Volume: ±1cm |
Max Size |
800mmX800mmX800mm(LxWxH) |
Min Size |
180mmX80mmX50mm(LxWxH) |
Customizable according to customers’ requirements |
