1. Provide code scanning, Dynamic Weighing and Volume measurement at the same time.
2. Focus on express delivery, logistics and cargo volume measurement, suitable for logistics, e-commerce, supermarket, warehousing and other industries.
|
Capability |
Up to 3000 pcs per hour |
|
Conveying Speed |
10-90 m/min |
|
Operating Temperature |
-10~40 degree |
|
Electrical |
1-phase 115/230VAC, 50/60 HZ |
|
Conveyor Height |
800mm±50mm |
|
Interface Options |
RS485/232, Ethernet |
|
Code Options |
Dynamic Scanner |
|
Code Type |
One-Dimension Code or QR Code |
|
Code Direction |
Parallel or Vertical |
|
Code Position |
On the top or side(3 and 5 sides scanning customizable) |
|
Max Weight |
50kg |
|
Tolerance |
Weight: ±50g Volume: ±1cm |
|
Max Size |
600mmX600mmX500mm(LxWxH) |
|
Min Size |
150mmX100mmX50mm(LxWxH) |
|
Customizable according to customers’ requirements |
|
