Static weighing and code scanning for small parcels for express delivery, which integrates automatic scanning, automatic photo taking, automatic weighing, and automatic piece counting functions. After the collected code and weight data are integrated by software, it is automatically entered into E-commerce, express delivery, Logistics management system etc..
|
Measuring Principle |
3D Vision Measurement System |
Voltage |
220V |
|
Volume Measuring Sensor |
WMPACK Sensor |
Automatic Measuring |
Accept |
|
Measuring Range |
5*5*5~70*70*70cm, ±10mm |
Data Uploading |
Accept |
|
Average Accuracy |
±6mm |
Local Storing |
Accept |
|
Measuring Speed |
1 pc/s |
Photo Storing |
Accept |
|
Data Output |
Excel/Http/TCP/Serial Port |
System Docking |
Accept |
|
Weighing Range |
Less than 100kg |
Secondary Developing |
Accept |
|
Weighing Accuracy |
±10g |
Automatic Scanning |
Accept |
|
Weighing Output Interface |
Rs232 |
Cost Calculating |
Accept |
|
Code Lens |
12mm/16mm |
More than 1 piece |
Accept |
|
Code Resolution |
10mils/0.254mm |
Weak Light Measuring |
Accept(no light) |
|
Code Resolution Speed |
100ms |
Operating Temperature |
-5~50 degree |
|
Material |
Stainless Steel |
Operating Humidity |
0~90% |
|
Code Scanner |
Can scan 1-dimension and QR code |
Code Type |
Code 128/39 |
|
Storage Function |
64G, accept storing every photo |
Code Type |
1&2 Dimension |
|
Operating System |
Win7/Win10 |
Code Camera Resolution |
1000W/600W |
|
Customizable According to Customers’ Requirements |
|||
